Looking for a lightweight, non-toxic, and maintenance-free energy storage solution as your home solar battery?
Youth Power deep-cycle Lithium Ferro Phosphate (LFP) batteries are optimized with proprietary cell architecture, power electronics, BMS and assembly methods.
They are a drop-in replacement for lead acid batteries, and much safer, it is regarded as the best solar battery bank with affordable cost.


Product Detail

Product Tags

Product Video

Product Specifications

Looking for a lightweight, non-toxic, and maintenance-free energy storage solution as your home solar battery?
Youth Power deep-cycle Lithium Ferro Phosphate (LFP) batteries are optimized with proprietary cell architecture, power electronics, BMS and assembly methods.
They are a drop-in replacement for lead acid batteries, and much safer, it is regarded as the best solar battery bank with affordable cost.
LFP is the safest, most environmentally chemistry available.
They are modular, lightweight and scalable for installations.
The batteries provide power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile.
Enjoy easy installation and cost with Youth Power Home SOLAR WALL BATTERY.
We are always ready to supply the first-class products and meet the various needs of the customers.

Battery Specifications
Model No YP48100-4.8KWH V2 YP51100-5.12KWH V2 YP48150-7.2KWH V2 YP51150-7.68KWH V2 YP48200-9.6KWH V2 YP51200-10.24KWH V2
Nominal Parameters
Voltage 48 V/51.2V 48 V/51.2V 48 V/51.2 V
Capacity 100 Ah 150 Ah 200Ah
Energy 4.8 /5.12 KwH 7.2/7.68 KwH 9.6 /10.24 KwH
Dimensions (L x W x H) 740*530*200mm 740*530*200mm 740*530*200mm
Weight 66/70kg 83/90 kg 101/110 kg
Basic Parameters
Life time(25℃) 10 Years
Life cycles(80% DOD, 25℃) 6000 Cycles
Storage time & temperature 5 months @ 25℃; 3 months @ 35℃; 1 month @ 45℃
Lithium Battery Standard UL1642(Cell), IEC62619.UN38.3, MSDS ,CE,EMC
Enclosure protection rating IP21
Electrical Parameters
Operation voltage 48 Vdc
Max. charging voltage 54 Vdc
Cut-off Discharge Voltage 42 Vdc
Max. charging and discharging current 100A(4800W) 120A(5760W) 120A(5760W)
Compatibility Compatible with all standard offgrid inverters and charge controllers. Battery to inverter output sizing keep 2:1 ratio.
Warranty Period 5-10 Years
Remarks Youth Power wall battery BMS must be wired in parallel only.                                                                        Wiring in series will void the warranty.
Finger Touch Version Available only for 51.2V 200AH, 200A BMS
5KWH-48V1

Product Feature

01. Long cycle life - product life expectancy of 15-20 years
02. Modular system allows storage capactiy to be easily expandable as power needs increase.
03. Proprietary architecturer and integrated battery management system ( BMS ) - no additional programming, firmware, or wiring.
04. Operates at unparalleled 98% efficiency for more than 5000 cycles.
05. Can be rack mounted or wall mounted in a dead space area of your home / business.
06. Offer up to 100% depeth of discharge.
07. Non-toxic and non-hazardous recylcable materials - recycle at end of life.

5kwh-48v (2)
5kwh-48v (3)
5kwh-48v (1)

Product Application

4.8KWH-V1

Product Certification

LFP is the safest, most environmentally chemistry available. They are modular, lightweight and scalable for installations. The batteries provide power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile. Enjoy easy installation and cost with YouthPOWER Home SOLAR WALL BATTERY.We are always ready to supply the first-class products and meet the various needs of the customers.

24v

Product Packing

packing

24v solar batteries are a great choice for any solar system that needs to store power. The LiFePO4 battery we carry is an excellent choice for solar systems up to 10kw as it has extremely low self-discharge and less voltage fluctuation than other batteries.

TIMtupian2

Our other solar battery series:High voltage batteries   All In One ESS.



• 5.1 PC / safety UN Box
• 12 Piece / Pallet



• 20' container : Total about 140 units
• 40' container : Total about 250 units
